Bucket scale

Functional characteristics:
1 full electronic digital weight display:
2 high precision, high safety bearing sensor with a good stability of the installation module.
3 can be applied to the stock of liquid, powder and other raw materials control.
4 in accordance with the actual situation, with the use of 3 or 4 sets of sensors.
5 can be combined with the purchase of the company's quantitative control system, to achieve quantitative automatic feeding or quantitative automatic nesting:
6 there are general non - Explosion - proof type specifications for the purchase.
The 7 module uses floating and semi floating combination, using the sensor to form the weighing measurement system, can automatically measure and weigh data, can store the computer and carry on the weighing data management.
Working principle：
1 installed in the tank at the bottom of the weighing module the weight signal is transmitted to the terminal box.
The 2 junction box is connected with each weighing module signal in parallel, and the angle difference is adjusted according to the load condition of each weighing module, and the collected weight signal is sent to the weighing end or the weight transmitter.
3 the weight signal is processed into the corresponding weight data by the weighing terminal or the weight transmitter.
Introduction of weighing system:
1 the control of the weighing system will start with the feed pump of the raw material until the qualified material is delivered to the reaction vessel. Which will include all the transmission, the control and interlocking of the discharge valve, the feed pump start and stop, the speed of feeding control, state detection, and all the data processing functions.
2 weighing system is composed of weighing unit, data processing unit and logic control unit. They work independently of each other, and they are closely linked in a question and answer session. In order to improve the automation degree of the system, it also improves the reliability of the system, so as to ensure the user can run without fault for a long time.
3 weighing system with full automatic, automatic and manual functions. Under no matter in what way, have a mandatory function. This function can start or stop some operations, in order to cope with the occurrence of some unexpected events, so that the system has a stronger strain capacity.
A. full automatic: automatic mode with computer monitoring and all data functions.
B.: automatically when the computer fails, cut off the computer in the control unit and the weighing logic unit, can operate according to the original proportioning program and predetermined precision. The formula will be entered by the field waterproof keyboard.
C. Manual: remove the chain function of the system, a single start pump and the use of weighing units of the function of the batching operation. This way is generally used for trial and emergency use.
4 system in the automatic mode (including automatic), to accept the request batching instructions, the alarm bell rang, notify the site, and then follow the order of start the feed pump system. To stop batching instructions, the system will stop the final discharge materials weighing tank.
